C&I ESS
ESS-TRENE Liquid Cooling
-
125kW /261kWh | Liquid Cooling ESS System
The SolaX ESS-TRENE Liquid Cooling is a high-efficiency C&I energy storage solution featuring multi-level protection (IP55) and liquid thermal management for enhanced safety. It achieves 99% efficiency with modular scalability (up to 3.44MWh) and supports AI-powered energy optimization via SolaX Cloud. Its wide voltage range (1000V) ensures seamless integration with diverse commercial applications.
-
Assista ao Vídeo
Product Advantage
The SolaX TRENE ESS features advanced liquid cooling technology that ensures optimal performance by maintaining cell temperature differences under 3°C. With a robust 314Ah LFP battery, it guarantees long-term reliability. Safety is a top priority, with a four-level fire protection system in place. Powered by intelligent energy management through the SolaXCloud, TRENE offers real-time monitoring and effortless operation, making it the perfect choice for C&I energy storage solutions.
Assured Safety
Four-level fire safety design secures minimal risk and loss
IP66 rating for inverter, IP55 for cabinet
AC Type II SPD for electrical safety
Advanced fault detection and response
High Performance
Premium LFP battery with guaranteed quality
High power density, compact design
Scalable up to megawatt-hours
Optimised space utilisation
Intelligent Design
Advanced energy management system
VPP ready with SolaX Cloud (IEEE 2030.5, OpenADR)
Supporting remote monitoring and maintenance
Supporting a variety of C＆I energy storage scenarios
Flexible Adaptability
Grid-connected support
Self-developed BMS & EMS via SolaXCloud
One year of local historical data storage
Cell-level balancing and smart temperature control
Product Parameters
-
TRENE-P125B261L-E-
AC SIDE (ON-GRID)
Rated AC Potência 125 kW Tensão AC nominal 3 / N / PE, 220 / 380 V 3 / N / PE, 230 / 400 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 261 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 1350 x 2355 x 1350 mm Peso 2810 kg Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55 If there is any change in product size and parameters, please refer to the latest information without prior notice.
-
-
TRENE-P124B261L-E
-
AC SIDE (ON-GRID)
Rated AC Potência 124.9 kW Tensão AC nominal 3 / N / PE, 220 / 380 V 3 / N / PE, 230 / 400 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 261 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 1350 x 2355 x 1350 mm Peso 2810 kg Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55 If there is any change in product size and parameters, please refer to the latest information without prior notice.
-
-
TRENE-P249B1044L-4H
-
AC SIDE (ON-GRID)
Rated AC Potência 249.8kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 12.5 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
-
TRENE-P250B1044L-4H
-
AC SIDE (ON-GRID)
Rated AC Potência 250 kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 12.5 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
-
TRENE-P499B1044L-2H
-
AC SIDE (ON-GRID)
Rated AC Potência 499.6 kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 13 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
-
TRENE-P500B1044L-2H
-
AC SIDE (ON-GRID)
Rated AC Potência 500kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 13 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
-
TRENE-P249B1044L-4H
-
AC SIDE (ON-GRID)
Rated AC Potência 249.8kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 12.5 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
-
TRENE-P250B1044L-4H
-
AC SIDE (ON-GRID)
Rated AC Potência 250 kW Tensão AC nominal 3/N/PE,230/400 V
3/N/PE,220/380 V
Rated AC frequency 50 Hz / 60 Hz -
DC SIDE
Tipo de Bateria LFP / 314 Ah Battery capacity 1044 kWh Rated battery Tensão 832 V -
SYSTEM PARAMETER
Dimensions (W×D×H) 2991 x2896 x2438 mm Peso 12.5 t Operating temperature range -30 ~ 55°C (＞45℃ derating) Max. operation altitude 3000 m Conceito de arrefecimento
Liquid cooling Proteção de entrada IP55
-
